Dongfeng KR Truck With XCMG 360 Degree GSQZ160 8Ton Folding Boom Crane
The Dongfeng KR truck mounted with the XCMG GSQZ160 8-Ton Folding Boom Crane (also known as a knuckle boom crane) is a common and highly functional specialized vehicle configuration, often sold by manufacturers like Chengli Special Automobile Co., Ltd
Lifting: The crane can load and unload the vehicle itself, making it a self-sufficient unit on a job site.
Transportation: The flatbed cargo box behind the cab is used to transport materials (e.g., steel, equipment, construction elements) after they have been lifted.
Applications: The truck is widely used in construction, logistics, utility work (e.g., pole setting, transformer installation), and general equipment handling. The knuckle boom's ability to fold and articulate makes it excellent for working in confined spaces compared to a straight boom crane.
Dongfeng KR Truck: This is the base vehicle, referring to the Dongfeng KR series of medium to heavy-duty truck chassis. This chassis provides the engine, cab, and frame structure necessary to mount the crane and carry cargo.
XCMG 360 Degree: XCMG (Xuzhou Construction Machinery Group) is one of the largest construction machinery manufacturers in the world. The "360 Degree" refers to the crane's ability to fully rotate on its base, giving it a wide working area.
GSQZ160: This is the model designation for the XCMG crane unit. The "GSQZ" series (or similar models like SQ8ZK3Q) generally refers to their knuckle boom (folding arm) truck-mounted cranes.
A key reference suggests the XCMG GSQZ160.4 Knuckle Boom Truck-mounted Crane has a Maximum Rated Lifting Capacity of 8,000 kg and a Maximum Lifting Torque of 167kN⋅m.
8 Ton: This specifies the maximum lifting capacity of the crane, which is 8,000 kg or 8 metric tons.
Folding Boom Crane: This specifies the type of crane. Also known as a knuckle boom crane, it has multiple hydraulic joints (like a human finger) that allow it to fold into a compact shape when not in use and maneuver around obstacles in tight spaces.
Dongfeng KR Truck With XCMG 360 Degree GSQZ160 8Ton Folding Boom Crane Technical sheet :
| Feature | Specification (Typical) |
| Drive Type | 4*2 (6-wheeler) is common for 8-ton cranes. |
| Engine | Cummins diesel engine (e.g., B190 33), typically around 190 HP. |
| Transmission | Manual, multi-speed (e.g., 6 or 8 forwards). |
| Emission Standard | Varies by export market (Euro 2, 3, 4, or 5). |
| Cabin | Single-row or sleeper cabin, often with air conditioning. |
| Steering | Available in Left Hand Drive (LHD) or Right Hand Drive (RHD). |
| Gross Vehicle Weight (GVW) | Approximately 15,000 kg (15 tons). |
| Cargo Box Capacity | Typically designed to carry an additional 10 tons of cargo. |
| Feature | Specification (GSQZ160 Knuckle Boom) |
| Max. Lifting Capacity | 8,000 kg (8 Tons) |
| Max. Lifting Moment | Typically around 160 to 168 kNm (16 to 16.8 t⋅m) |
| Boom Type | Folding Boom (Knuckle Boom) - Allows the crane to fold compactly when not in use. |
| Boom Sections | Varies, but commonly 4 or 5 sections. |
| Max. Hydraulic Outreach | Approximately 12 to 12.75 meters. |
| Rotation Angle | 360∘ (Full continuous rotation) or 410∘. |
| Outriggers | Equipped with hydraulic H-type outriggers for stability during lifting operations. |
| Operation | Manual joystick controls are standard; remote control is often an available option. |
| Cab | Chassis Brand | Dongfeng |
| Production Year | 2025 |
| Overall Dimension | 7840*2340*3060(mm) |
| Tyre above paiting color | Black |
| Cabin | Single cabin |
| Air Conditioner | With |
| Drive Type | 4*2 |
| Steering Wheel | Left Hand Driver |
| Transmission | Manual |
| Wheelbase | 4500 |
| Tyre Specification | 10.00R20 |
| Tyre No. | 6+1 |
| Max Speed | 98km/h |
| Paint | Red |
| Engine | Fuel Type | Diesel |
| Engie Model | B190 33 |
| Engine Brand | Cummins |
| Power | 190HP |
Dongfeng KR Truck With XCMG 360 Degree GSQZ160 8Ton Folding Boom Crane Details :
About Chengli Special Automobile Co., Ltd
Location: The company is headquartered in Suizhou City, Hubei Province, which is known as the "Capital of China's Special Purpose Vehicles."
Establishment: The predecessor, Chengli Special Automobile Co., Ltd., was established in September 2004. The CLW Group has since grown into a large, diversified enterprise.
Products: Chengli is a large-scale, government-designated manufacturer of various special-purpose vehicles. Their extensive product range often includes:
- Sanitation Trucks: Garbage trucks (compactor, hook-lift, swing-arm, etc.), water sprinkler trucks, sewage suction trucks, fecal suction trucks, and road sweepers.
- Tank Trucks/Trailers: Fuel tankers, LPG (Liquefied Petroleum Gas) tankers and storage tanks, chemical liquid tank trucks, and bulk cement/feed trucks.
- Construction & Engineering Vehicles: Truck-mounted cranes, dump trucks, concrete mixer trucks, wrecker/tow trucks, and aerial platform trucks (manlifts).
- Specialized Vehicles: Fire fighting trucks, refrigerated trucks, LED advertising trucks, ambulance cars, and road maintenance vehicles.
Market Position: It is often cited as the largest special vehicle manufacturer in Central China, and their products are sold throughout China and exported to over 30 countries and regions, including South America, the Middle East, Central Asia, Southeast Asia, and Africa.
Certifications: The company holds various national and international certifications, including ISO quality, environmental, and occupational health and safety management systems, as well as China Compulsory Certification (CCC) and qualifications for pressure vessels (A2, C2, C3).
Partnerships: They cooperate with major truck chassis manufacturers like Dongfeng, FAW, Foton, Sinotruk, Isuzu, JAC, and JMC.
Established in Sep. 2004,Chengli Special Automobile Co., Ltd is an important branch of CLW group with registered capital 100,000,000 RMB(14
millions US Dollars) and total capital 6,000,000,000(840 millions US Dollars).
Chengli Special Automobile Co., Ltd Overseas Market
Africa: This is a major market for Chengli. Specific countries mentioned in their export records and company information include:
- West Africa: Nigeria, Ghana, Togo, Mali, Congo, Congo-Brazzaville.
- East/Southern Africa: Tanzania, Zambia, Angola, Ethiopia, South Africa.
- North Africa: Algeria.
Southeast Asia: A strong traditional market, often including:
- Philippines, Vietnam, Myanmar, Thailand, Cambodia, and Laos.
Middle East / Central Asia:
- The Middle East (Mid East) region in general.
- Central Asia (e.g., Kazakhstan, Uzbekistan, Russia, Mongolia).
South America / Central America:
- South America is a significant focus. (e.g., Venezuela, Dominican Republic, Chile, Bolivia, Ecuador).
- Central America.
Oceania: Countries like Australia and New Zealand.
Eastern Europe.
Trucks from Chengli Special Automobile Co., Ltd have been sold to more than 29 provinces in China and more than 80 overseas countries and regions in
Asia, Africa, South America, middle east and so on, such as Russia, Mongolia, Philippines, Vietnam, Cambodia, Myanmar, Laos, Kazakhstan, Uzbekistan,
Kyrghzstan, Tanzania, Zambia, Nigeria, Australia, Chile, Bolivia, Ethiopia, Sudan, Malaysia, Congo, El Salvador, Iraq, New Zealand, Chile, Bolivia, Argentina and also truck body for client drawing
